Titanium Nitride Nanoparticles 99.9%, 20nm

Short Description:

  • CAS No.: 25583-20-4
  • Molecular Formula: TiN
  • Quality Standard: 99.9%
  • Minimum Order: Depends on your requirement
  • MW: 61.87
  • Melting point: 2930 °C (lit.)
  • Boiling point: 0°C
  • density: 5.24 g/mL at 25 °C (lit.)
  • RTECS: XR2230000
  • Fp: 0°C
  • Specific Gravity: 5.24
  • RIDADR: UN3178
  • WGK Germany: 3
  • TSCA: Yes
  • HazardClass: 4.1
  • PackingGroup: III

Product Detail

Product Tags

308335111202441
Anhui-Fitech-Materials-Co-Ltd- (27)
Anhui-Fitech-Materials-Co-Ltd-

Basic information:

Titanium nitride nanoparticle has a high melting point (2950 °C), high hardness, high-temperature chemical stability and excellent thermal conductivity properties.

Also, it possesses high performance infrared absorption and UV-shielding more than 80%. Its sintering temperature is low. Nano titanium nitride (TiN) is an excellent ceramic material.

Model

APS（nm）

Purity（%）

Specific surface area（m2/g）

Volume density（g/cm3）

Density（g/cm3）

Crystal form

Color

ZY-N-002

40

>99.9

68

0.12

5.4

cube

black

Application:

1.Be used in producing PET beer bottles and plastic packaging materials as high barrier.

2.Be used in PET engineering plastics.

3.Be used in solar vacuum tube as high sunlight absorbers( if added in the coating,the water temperature will increase by 4 to 5 degrees)

4.Applications of high thermal emissivity coating:Be used in high-temperature furnace for energy-saving and to produce new energy-saving glass coating in military industry.

5.Be used in cemented carbides as the alloy modificators. Grain refinement can enhance toughness and hardness of the alloy and reduce certain rare metals dosage.

6.Composite rigid cutting tools, high-temperature ceramic conductive material, heat resistant material, dispersion strengthened materials.

7.Artificial limbs; Barrier layer in contact and interconnect metallization; Biological materials cutting tools; Gate electrode in metal-oxide-semiconductor (MOS) transistors; Low-barrier Schottky diode; Optical devices in aggressive environments; Plastic molds; Prostheses; Wear-resistant coating.

Storage Conditions

Damp reunion will affect its dispersion performance and using effects, therefore, this product should be sealed in vacuum and stored in cool and dry room and it should not be exposure to air. In addition, the product should be avoided under stress and spark because it is flammable.

12

Certificate

The products have been approved by FDA,REACH,ROSH,ISO and other certification, in line with national standards.

b7d457348c43fdbc460183dbae04cf7
950c4aec877e06940eb739c44c856c0
02edcb14670b02c8cb087d00580860c
55b32e9848a2d16a8c1bc72070f10df
5892ef06491e4769dde29fc3e034c95

Advantage
Quality First
Competitive Price
First-class Production Line
Factory Origin
Customized Services

hjgfyut
hgfdduyt
gfhduty

Factory

factory (4)
factory (3)
factory (2)
factory (1)

Packing

1kg/ bag; 25kg/ barrel;
20 tons/1×20‘FCL Shipment.

Packing-1-Cobalt-powder_副本
Packing-1-Cobalt-powder_副本
Packing-1-Cobalt-powder_副本

FAQ:
Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
