Stainless Steel Powder 304 Feedstock for Metal Injection Molding (MIM)

Short Description:

  • Model NO.: 304L
  • Composition: Ferrous Steel Scrap
  • Standard: ASTM, JIS, GB
  • Surface Treatment: Polished
  • Shape: Spherical Powder
  • Application: Aeronautical Parts
  • Main Products: 304L Stainless Steel
  • Mobility: ≤18s/50g
  • Bulk Density: ≥4.10/cm3
  • Oxygen Content: ≤650ppm
  • Nitrogen Content: ≤200ppm
  • Compressive Strength /MPa: 505±50
  • Yield Strength /MPa: 166±50
  • Elongation /%: 56±5
  • Transport Package: III

Product Detail

Product Tags

Anhui-Fitech-Materials-Co-Ltd.Nano6
Anhui-Fitech-Materials-Co-Ltd.Nano9_-副本
Anhui-Fitech-Materials-Co-Ltd.Nano7_-副本

Basic information:

304L stainless steel, also known as ultra-low carbon stainless steel, is a versatile stainless steel material.

304L is a variant of 304 stainless steel with a lower carbon content and is used in applications where welding is required. The lower carbon content minimizes the carbides precipitated in the heat-affected zone near the weld, which can lead to intergranular corrosion (welding erosion) in stainless steel in some environments.

Resistivity 0.73 Ω·mm2·m-1

Melting point 1398~1420ºC

304L stainless steel forging performance is poor, deformation is more difficult.

Corrosion resistance :304 stainless steel has good corrosion resistance at room temperature, and can resist the corrosion of most acids, alkalis and some salt solutions.

High temperature strength :304 stainless steel in high temperature environment still maintains high strength and hardness, suitable for high temperature working environment applications.

Good processing performance :304 stainless steel is easy to process and form, and can meet the needs of different shapes and sizes.

High strength :304 stainless steel has high strength and tensile strength of about 520MPa, which is one of the excellent structural materials.

Good thermal stability :304 stainless steel has good high temperature resistance and can be used for a long time at 600°C, so it can also be used to make heaters, heat exchangers and other equipment.

Items Chemical Composition(wt%) Remark
Alloy C Si Cr Ni Mn Mo Cu W V Fe
304L - - 18.0-20.0 8.0-12.0 - - - - - Bal. /

Linear expansion coefficient α/(10-6/ºC) (between the following temperatures /ºC)

20~100 20~200 20~300 20~400
16.0 16.8 17.5 18.1

Thermal conductivity λ/W(m·ºC)-1 (at the following temperatures /ºC)

20 100 500
12.1 16.3 21.4

Application:

304 stainless steel has a wide range of applications in many fields because of its excellent corrosion resistance, high temperature strength and good processing properties.

Particle Size TappingDensity Flowability Particle Size   Distribution (μm)
    (g/cm³)     (s/50g) D10 D50 D90
15-45μm 4.4-4.9 ≤30 17-22 30-34 48-55
15-53μm 4.4-4.9 ≤30 20-25 32-37 51-61
Anhui-Fitech-Materials-Co-Ltd.Nano8_-副本

Certificate

The products have been approved by FDA,REACH,ROSH,ISO and other certification, in line with national standards.

b7d457348c43fdbc460183dbae04cf7
950c4aec877e06940eb739c44c856c0
02edcb14670b02c8cb087d00580860c
55b32e9848a2d16a8c1bc72070f10df
5892ef06491e4769dde29fc3e034c95

Advantage
Quality First
Competitive Price
First-class Production Line
Factory Origin
Customized Services

hjgfyut
hgfdduyt
gfhduty

Factory

factory (4)
factory (3)
factory (2)
factory (1)

Packing

1kg/ bag; 25kg/ barrel;
20 tons/1×20‘FCL Shipment.

Packing-1-Cobalt-powder_副本
Packing-1-Cobalt-powder_副本
Packing-1-Cobalt-powder_副本

FAQ:
Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
