Powder 50μm Yttrium Stabilized Zirconia Dioxide CAS 1314-23-4 Nano Zirconia

Short Description:

CAS No.: 1314-23-4
Molecular Formula: ZrO2
Quality Standard: 99.9%
Packing: : 25kg/ barrel
Minimum Order: Depends on your requirement
Density: 5.89 g/mL at 25 °C(lit.)
Boiling Point: 5000 °C(lit.)
Melting Point: 2700 °C(lit.)
Molecular Weight: 123.223
Flash Point: 5000°C
Stability: Stable
Water Solubility: insoluble
RIDADR: UN1993
WGK Germany: 1
RTECS: ZH8800000
Packaging Group: III
Hazard Class: 3
HS Code: 2825600090
EINECS: 215-227-2

Send email to us

Product Detail

Product Tags

Basic information:

Zirconia granulation powder series products, yttrium stabilized zirconia granulation powder YSZ is formed by spray drying granulation process of zirconia powder particles, granulation diameter of about 50um, its primary particle size is about 50nm. The yttrium stabilized zirconia powder produced by the company through chemical method ensures the balanced dispersion of yttrium oxide, and strict quality control ensures the stable quality of each batch of products. After the yttrium stabilized zirconia powder is granulated, the powder flows smoothly and is easy to use.

Specification

Model	ZY-VK-R50Y3R	ZY-VK-R50Y5R	ZYVK-R50Y8R
Crystal Form	3Y tetragonal phase	5Y tetragonal phase	8Y tetragonal phase
ZrO₂% (+ HfO₂)	94.7±0.3	91.5±0.3	86.5±0.3
Y₂O₃（wt%）	5.3±0.3	8.5±0.3	13.5±0.3
Al₂O₃% ≤	0.01	0.01	0.01
SiO₂%≤	0.01	0.01	0.01
Fe₂O₃%≤	0.01	0.01	0.01
CaO%≤	0.005	0.006	0.005
MgO%≤	0.005	0.005	0.005
TiO₂%≤	0.002	0.002	0.002
Na₂O%≤	0.005	0.005	0.005
APS um	50	50	50

Application:

Ceramics made of zirconia granulation powder are known as ductile ceramics because of their stress-induced phase change toughness. They have good mechanical properties, and the surface of the products produced is smooth and clean. They are now used in various fields.

3mol yttrium oxide stabilized tetragonal zirconia granulation powder is a widely used material at present. 3mol yttrium stabilized zirconia granulation powder, suitable for mechanical pressing and isostatic pressing.

8mol yttrium stabilized zirconia granulation powder is a cubic zirconia sintered body with ionic conductivity, which is suitable for oxygen sensors and solid oxide fuel cells.

Certificate

The products have been approved by FDA,REACH,ROSH,ISO and other certification, in line with national standards.

Advantage
Quality First
Competitive Price
First-class Production Line
Factory Origin
Customized Services

Factory

Packing

1kg/ bag; 25kg/ barrel;
20 tons/1×20‘FCL Shipment.

FAQ:
Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
