Best Price Sell High Quality H11 Powder for Laser Cladding Products
Basic information:
1. High thermal strength: H11 steel has excellent high temperature strength and thermal stability, and can maintain high hardness and strength under high temperature environment.
2. Good heat resistance fatigue performance: H11 steel has good heat resistance fatigue performance and can maintain stable performance under long-term high temperature working conditions.
3. Excellent processing performance: H11 steel is easy to process and heat treatment, and can obtain good surface hardness and wear resistance.
H11 is a kind of hot work die steel with excellent thermal strength and thermal fatigue properties, which is often used in the manufacture of hot work molds, die casting molds and plastic molds.
| Items | Chemical Composition(wt%) | Remark | |||||||||
| Alloy | C | Si | Cr | Ni | Mn | Mo | Cu | W | V | Fe | |
| H11 | 0.32-0.45 | 0.6-1 | 4.7-5.2 | - | 0.2-0.5 | 0.8-1.2 | - | - | 0.2-0.6 | Bal. | - |
Laser cladding refers to the process method of placing the selected coating material on the surface of the coated substrate in different feeding methods to melt a thin layer on the surface of the substrate at the same time, and forming a surface coating with very low dilution after rapid solidification, and forming a metallurgical combination with the substrate to significantly improve the wear resistance, corrosion resistance, heat resistance, oxidation resistance and electrical characteristics of the base surface. Thus, the purpose of surface modification or repair is achieved, which not only meets the requirements of specific properties of the material surface, but also saves a lot of valuable elements.
Compared with surfacing welding, spraying, electroplating and gas deposition, laser cladding has the characteristics of small dilution, dense structure, good combination of coating and matrix, many suitable cladding materials, and large changes in particle size and content, so the application prospect of laser cladding technology is very broad.
Application:
1. Hot working mold: H11 steel is often used to manufacture hot working molds, such as forging molds, hot pressing molds, etc., which can maintain stable hardness and strength under high temperature conditions, and has good wear resistance and thermal fatigue properties.
2. Die casting mold: Because H11 steel has good thermal stability and heat resistance fatigue properties, it is often used in the manufacture of die casting molds, which can withstand high temperature and high pressure conditions.
3. Plastic mold: H11 steel is also suitable for the manufacture of plastic mold, can maintain stable performance under high temperature conditions, with good wear resistance and surface hardness.
| Particle Size | TappingDensity | Particle Size Distribution (μm) | ||
| (g/cm³) | D10 | D50 | D90 | |
| 15-53μm | 4.4-4.9 | 17-22 | 30-34 | 48-55 |
| 53-120μm | 4.5-4.8 | 49-56 | 70-78 | 96-110 |
| 53-150μm | 4.5-4.8 | 56-66 | 85-97 | 125-150 |
Certificate
The products have been approved by FDA,REACH,ROSH,ISO and other certification, in line with national standards.
Advantage
Quality First
Competitive Price
First-class Production Line
Factory Origin
Customized Services
Factory
Packing
1kg/ bag; 25kg/ barrel;
20 tons/1×20‘FCL Shipment.
FAQ:
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
