Antimony Tin Oxide ATO Nanopowder 10 Nm Nanoparticle Conductive Thermal Insulation Radiation Protection Hydrophilic

Short Description:

  • CAS No.: 128221-48-7
  • Molecular Formula: ATO
  • Quality Standard: 99.9%, 99.99%
  • Minimum Order: Depends on your requirement
  • MW: 260.5
  • Density: 1.01 g/mL at 25 °C(lit.)
  • Main component: SnO2:Sb2O3=90:10
  • Exact Mass: 441.684418

Product Detail

Product Tags

氧化锡锑1
1 (1)
微信图片_20230719160037

Basic information:

High-frequency plasma gas-phase combustion method for the preparation of nano-tin-antimony oxide powder ATO nano-superfine powders, high purity products, low bulk density (forty per cent lower than similar products in China), easily dispersed into a stable nano-slurry, greatly reducing the dispersion of nano ATO powder dispersal difficulties, improve the dispersion efficiency, greatly improve the visible light transmittance of the nano-slurry, the film's surface homogeneity. Nano antimony tin oxide powder, nano-supermicron powder with non-resistive transparent conductivity in the semiconductor field, can be applied to glass, various plastics, etc. to play an anti-static and transparent conductivity required in the field of application. Conductivity: uniformly dispersed conductive nanoscale particles of conductive interactions to form a conductive film, conductive film in the charge movement can achieve high transmittance and anti-static (106-1012Ω) Transparency: ATO nanoscale particles of ultrafine particles of visible light (400 nm-800 nm) absorption rate is extremely weak, and the visible light is difficult to scatter the size of the particles composed of, so there is transparency. Durability: chemically stable tin antimony oxide nanoparticles are composed of metal oxide powder, which can maintain the conductive property due to small changes in physical properties caused by heat, humidity and other external environments.

Specification

Item Product Name SnO2:Sb2O3 APS Purity Color SSA Bulk Density Heat Resistance Powder Resistivity (Ω.cm)
ZY-G06 Antimony Tin Oxide Nanoparticles 90:10 50nm 99.90% Blue 45-75m2/g 1.01g/cm3 1100℃ 106-108

Application:

1.Antimony Tin Oxide Nanopowder ATO has excellent quality of electricity and optics. Due to its good conductivity, ATO Nanopowder can be widely used in the industry of coating, chemical fiber and polymeric membrane as anti-static material.

2.Antimony Tin Oxide Nanopowder has more advantaged properties in dispersion, weather-ability, thermoplastic, wear resistance, and security than some other conductive materials such as graphite, surfactant, and metallic powder etc.

3.The nano ATO can also be used in the field of optoelectronic display devices, transparent electrode, solar battery, liquid crystal display, catalysis and other industries with its advantages. Chemical resistance: acid resistance, alkali resistance, lightfastness, organic solvents resistance, antioxidant and inflaming retarding.

4.ATO can be used in LCD, LED and ECD. 2. ATO for Transparent electrode and solar battery.

5.ATO can shield heat when it is used in hot mirror, building or glass curtain wall.

6.ATO can be used in the glass of car, train and plane to protection against fog and frost.

7.Due to the decline of the microwave, ATO can be used in computer room and radar shielding and protecting area where needs to shield electromagnetic wave.

氧化锡锑3

Certificate

The products have been approved by FDA,REACH,ROSH,ISO and other certification, in line with national standards.

b7d457348c43fdbc460183dbae04cf7
950c4aec877e06940eb739c44c856c0
02edcb14670b02c8cb087d00580860c
55b32e9848a2d16a8c1bc72070f10df
5892ef06491e4769dde29fc3e034c95

Advantage
Quality First
Competitive Price
First-class Production Line
Factory Origin
Customized Services

hjgfyut
hgfdduyt
gfhduty

Factory

factory (4)
factory (3)
factory (2)
factory (1)

Packing

1kg/ bag; 25kg/ barrel;
20 tons/1×20‘FCL Shipment.

Packing-1-Cobalt-powder_副本
Packing-1-Cobalt-powder_副本
Packing-1-Cobalt-powder_副本

FAQ:
Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
